| 公 称 型 号 |
外形尺寸 | LM 滑块尺寸 | H3 | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 高H | 宽W | 长L | B | C | M×l | L1 | N | E | 油 嘴 | |||
| M5C M5N |
6 | 12 | 17 20 |
8 | - - |
M2×1.5 | 9.4 12.4 |
1.2 | - - |
- - |
1 | |
| M7C M7N M7L |
8 | 17 | 19.8 24.3 31.8 |
12 | - 8 13/(12) |
M2×2.5 | 9.6 14.1 21.6 |
1.5 | - - - |
- - - |
1.5 | |
| M9C M9N M9L |
10 | 20 | 22.4 31.3 41.4 |
15 | - 10 16/(15) |
M3×3 | 11.8 20.7 30.8 |
2.2 | - - - |
- - - |
2 | |
| M12C M12N M12L |
13 | 27 | 26.4 34.9 45.4 |
20 | - 15 20 |
M3×3.5 | 12.8 21.3 31.8 |
2.7 | - - - |
- - - |
3 | |
| M15C M15N M15L |
16 | 32 | 34.4 44.4 59.4 |
25 | - 20 25 |
M3×4 | 17.7 27.7 42.7 |
3.1 | 4 4 4 |
A-M3 | 4 | |
| M20C M20N M20L |
30 | 40 | 39.8 51.8 69.8 |
30 | - 25 30 |
M4×6 | 22.2 34.2 52.2 |
4.2 | 4 4 4 |
A-M3 | 5 | |
| 公称 型号 |
LM 滑轨尺寸 | 基本 额定负载 |
允许静力矩 kM·m | 重量 | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 宽 W1 |
W2 | 高 H1 |
值 G |
孔距 P |
d1×d2×h | C N |
Co N |
Mp | My | Mr | LM 滑块 g |
LM 滑轨 g/m |
||||
| 单滑块 | 双滑块 | 单滑块 | 双滑块 | 单滑块 | ||||||||||||
| M5C M5N |
5 +0 -0.02 |
3.5 | 3.7 | 5 | 15 | 2.4×3.6×0.8 | 516 631 |
757 1009 |
1.3 2.2 |
7.1 11.6 |
1.3 2.2 |
7.1 11.6 |
2.01 2.67 |
3.1 4.0 |
139 | |
| M7C M7N M7L |
7 +0 -0.02 |
5 | 5 | 5 | 15 | 2.4×4.2×2.3 | 901 1197 1631 |
1136 1703 2650 |
1.9 4.2 10.1 |
11.8 23.1 50.0 |
1.9 4.2 10.1 |
11.8 23.1 50.0 |
4.14 6.22 9.67 |
6.4 9.0 12.6 |
253 | |
| M9C M9N M9L |
9 +0 -0.02 |
5.5 | 6 | 7.5 | 20 | 3.5×6×3.5 | 1180 1721 2375 |
1485 2545 4030 |
3.1 9.3 21.9 |
17.9 46.6 102.8 |
3.1 9.3 21.9 |
17.9 46.6 102.8 |
6.90 11.84 18.74 |
9.9 17.1 25.2 |
391 | |
| M12C M12N M12L |
12 +0 -0.025 |
7.5 | 8 | 10 | 25 | 3.5×6.5×4.5 | 2175 3023 4246 |
2385 3816 6200 |
5.4 14.4 34.8 |
32.9 75.8 169.1 |
5.4 14.4 34.8 |
32.9 75.8 169.1 |
14.79 23.66 38.44 |
19.8 31.5 45.9 |
679 | |
| M15C M15N M15L |
15 +0 -0.025 |
8.5 | 10 | 15 | 40 | 3.5×6.5×4.5 | 3418 4540 6492 |
3895 5842 9737 |
12.2 28.6 73.5 |
71.6 148.7 351.2 |
12.2 14.4 34.8 |
71.6 148.7 351.2 |
29.99 44.99 74.98 |
37.8 57.6 85.5 |
1071 | |
| M20C M20N M20L |
20 +0 -0.03 |
10 | 11 | 20 | 60 | 6×9.5×5.5 | 4512 6191 8396 |
5299 8328 12870 |
20.7 50.2 118.6 |
115.9 252.7 554.4 |
20.7 50.2 118.6 |
115.9 252.7 554.4 |
54.05 84.94 131.27 |
80.1 119.7 176.4 |
1572 | |
